◆    Integrative structure. Low deflection,low oscillating,high stability.

  ◆    high-strength stainless steel drive system and high precision aluminum alloy SYN gear

  ◆    Load weight up to 50KG, available for containg ultra long focal-length zoom lens

  ◆    Auto angle-calibrate function

  ◆    All-weather design, adapted to  -40℃～+60℃

  ◆    High-strength aluminum-alloy housing, anti-impact, anti-corrosion,IP66. With wiper and demist function.

  ◆    Pan:360°,Non-Limited Position, Tilt 120°(-60°～+60°)

  ◆    Built-in OSD Menu,support changing information and parameter of the dome, support setting and calling
         Presets, tour, scan, pattern, camera mode, display name and etc.

  ◆    Up to 128 presets(titles can be set), support tour and preset running time and speed reserve.

  ◆    8 programmable zones with titles, 4 PATTERN, Each recording time is not less then 180s

  ◆    4 Scan,support scan between left and right limited at an appointed speed.

  ◆    Park action function, support auto-calling presets or start-up tour, pattern and scan after dome idle for a
         period of time

  ◆    Real time function, support pre-seting dome action at an appointed time in any day or month via OSD menu

  ◆    Built-in memorizer can store parameters of camera & functions of PTZ.

  ◆    Temperature display function, can survey the temperature inside of dome.

  ◆    PT postions nad Zoom display

  ◆    Alarm fucntion, 7 in and 2 out

  ◆    Privacy masking, to shield the private region from displaying on the screen.

  ◆    Power-up function, available for pre-setting the PTZ reboot action via OSD menu

  ◆    Communication: RS485/RS422 ,Manchester,BI-PHASE

  ◆    Built-in multi-protocols and fully compatible with PELCO-D、PELCO-P、KALATEL, VICON, BOSCH(PHILIPS), SENSORNT, AD, VIDO B02, etc.

  ◆    IP66 all-weather protect, built-in constant temperature device

  ◆    lightning-proof: Video,communication and power input port all have 2-3 grade protective circuits

  ◆    Built-in TVS4000V lightning-proof, surge-proof and wave-proof.
